4 GANG SWITCH PANEL RED ILLUMINATED

+ 2 USB PORTS + CIGARETTE OUTLET

This high-quality 4-gang Gang Switch Panel also comes with Daul USB ports for all your charging needs. This panel also has a cigarette outlet. The panel is splashproof, perfect for boats and marine or outdoor applications. Quality aluminum face panel. CE Certified.

Easy to install. Cut-out hole required. Then fix it to the dash using the stianless screws provided.

SPECIFICATIONS:

• Illumination: BLUE
• IP Rating: IP69 Water Resistant
• Approved: CE
• Dual USB Ports: 3.1A (1A + 2.1A)
• USB Input: DC12-24V
• USB Output: DC 5V / 1A & 5V / 2.1A
• Cigarette Output Voltage: 12-24V
• Loop Circuit: ON/OFF
• Input Voltage: DC12V/24V
• Splashproof
• Anti-Corrosion
• Can be Installed horizontally or vertically
• Accessories angles can be adjusted
• Rubber seal cap
• Prewired panel
• Mounting Screws stainless steel
• Switch Labeling Stickers
• 1YR Warranty

DIMENSIONS:

• Overall size: 130X 120 X 55MM
• Sizes are only approx.
